POTABLE WATER · CERTIFIED SEALING SOLUTIONS

CUSTOM-CUT NSF 61
EPDM GASKETS
& SEALS

TIPCO Technologies fabricates NSF/ANSI/CAN 61 & 372 certified gaskets and seals from American Biltrite EPDM sheet stock — cut to your exact dimensions for drinking water systems, municipalities, and utility infrastructure.

REQUEST A QUOTE VIEW SPECIFICATIONS

Certified sheet.
Cut to your spec.
Ready for potable water.

American Biltrite's AB-576 EPDM compound is NSF/ANSI/CAN 61 & 372 certified for direct contact with drinking water — meaning every gasket, liner, or seal cut from this material meets the health-effects standard for water system components, from municipal treatment facilities to building plumbing infrastructure.

TIPCO Technologies stocks American Biltrite sheet and cuts it to your exact dimensions in-house. Stock sizes, custom profiles, full-face flanges, ring gaskets, and sheet cuts — all traceable to the same certified compound. No substitutions, no supply-chain ambiguity.

TIPCO Sealing Technologies — gasket and seal fabrication is a core TIPCO capability. Our fabrication team cuts NSF 61 EPDM sheet to water-jet, die-cut, and hand-cut profiles from stock or your drawings, typically same day.

MATERIAL PROPERTIES

FULL TECHNICAL DATA — AB-576 EPDM

Property	Test Standard	Value	Notes
Compound	—	EPDM (AB-576)	Ethylene Propylene Diene Monomer
Durometer Hardness	ASTM D2240	75 ±5 Shore A	Medium-firm; suitable for flanged joints
Tensile Strength	ASTM D412	1,500 PSI min.	Ensures integrity under compression
Compression Set	ASTM D395-B	22 hrs @ 70°C	Low set; retains seal force over time
Max. Service Pressure	—	250 PSIG	17 bar; for gasket applications
Service Temperature	—	−40°F to +275°F	−40°C to +135°C; hot & cold water service
Ozone Resistance	ASTM D1149	Excellent	Suitable for outdoor / UV-exposed applications
NSF/ANSI 61 Certification	NSF International	Certified	Drinking water system components — health effects
NSF 372 Certification	NSF International	Certified	Lead-free compliance
SDWA Compliance	2014 Safe Drinking Water Act	Compliant	Meets federal lead-content limits
AWWA Suitability	AWWA C111 / C207	Approved	Rubber-gasket joints for ductile-iron pipe
Manufacturer QMS	—	ISO 9001 / ISO 14001	American Biltrite — certified since 1908

STOCK DIMENSIONS

AVAILABLE THICKNESSES

1/16

INCH

1.59 mm (0.0625″)

Series 386-04-482

1/8

INCH

3.18 mm (0.125″)

Series 386-08-482

3/16

INCH

4.76 mm (0.1875″)

Series 386-12-482

1/4

INCH

6.35 mm (0.25″)

Series 386-16-482

All thicknesses available in 48″ width. Standard cuts: 24×12″, 48×12″, 48×20″, 48×36″, 48×48″. Custom dimensions cut to order.

END USES

WHERE NSF 61 EPDM IS REQUIRED

WATER METER GASKETS

Flanged and full-face gaskets for residential, commercial, and municipal water meters. NSF 61 certification is required at the point of meter connection in most jurisdictions.

POTABLE WATER TANKS

Manhole cover gaskets, access port seals, and flanged connection gaskets for atmospheric and pressurized potable water storage tanks.

PUMP & FILTER SEALS

Drinking water booster pumps, pressure filters, and carbon filter housings require NSF 61 certified elastomers at every wetted surface seal.

FLANGED PIPE JOINTS

Full-face and ring-type gaskets for ductile iron, PVC, and steel flanged pipe joints in municipal distribution — AWWA C111/C207 compatible.

HYDRANTS & VALVES

Fire hydrant and gate valve seat gaskets in distribution mains. EPDM's ozone resistance makes it the preferred compound for above-grade and UV-exposed applications.

TREATMENT EQUIPMENT

Chlorination systems, softener vessels, UV disinfection chambers, and membrane filter housings — any wetted component contacting drinking water.

WHY TIPCO

THE DISTRIBUTOR DIFFERENCE

FABRICATION

CUT IN-HOUSE, SAME DAY

TIPCO operates in-house gasket fabrication across its network. Water-jet, die-cut, and hand-cut profiles from certified sheet stock — supply your drawing or a standard ANSI flange dimension, and we cut and ship it.

TRACEABILITY

CERTIFIED MATERIAL, NO GAPS

Every piece of EPDM we cut comes from American Biltrite's NSF 61 & 372 certified compound. No substitutions, no grey-market sheet. Full material traceability available for municipal bid packages and inspection records.

AVAILABILITY

39 LOCATIONS, STOCKED DEEP

As the largest stocking distributor in the Mid-Atlantic, TIPCO carries sheet inventory in multiple thicknesses ready to cut. Rush turnaround for emergency repairs and planned maintenance work alike.
